16
T1 Quick Reference Guide
DPM Central Station Interface: Waveform Review (Disclosure) storage on the
T1 bedside monitor and DPM Central Station are independent.
Panorama Central Station Interface: Full disclosure storage on the T1 bedside
monitor and Panorama Central Station are independent.
VOLUMES
The alarm volume, key volume, and QRS volume can be adjusted on the T1
monitor.
Alarm Volume
To adjust the alarm volume on the T1 monitor:
a. Scroll and select Alarm Setup >> from Main Menu
(quick key)
b. Scroll and select Others tab
c. Select Alm Volume to adjust medium and low priority alarm volumes
d. Select volume ranging from X*-10 (0=Off 10=Max)
e. Select High Alarm Volume to adjust high alarm volumes
f. Select volume ranging from Alm Volume+0 to Alm Volume+2
g. Select Main Menu
(quick key) or to return to the main display
*The minimum volume range(X) is configurable.
Key Volume
To adjust the key volume on the T1 monitor:
a. Scroll and select Screen Setup >> from Main Menu
(quick key)
b. Select Key Volume
c. Select volume ranging from 0-10 (0=Off 10=Max)
d. Select Main Menu
(quick key) or to return to the main display
Beat Tone
To adjust the beat tone (QRS tone) volume on the T1 monitor:
a. Select ECG waveform or ECG numeric tile to enter the ECG Setup menu
b. Scroll and select Others >>
c. Select QRS Volume
d. Select volume ranging from 0-10 (0=Off 10=Max)
To Next Page
