15
T1 Quick Reference Guide
Central Station Interface: Trend storage, display interval, and printing length
on the T1 bedside monitor and Central Station are independent.
Arrhythmia and Alarm Events
The Events tab stores 100 physiological and arrhythmia events for a patient
based on the Alarm Setup menu.
To view and print a patient's alarm event on the T1 monitor:
a. Scroll and select Review >> from Main Menu
(quick key)
b. Select Events tab
c. Scroll and select event
d. Select Details to view the 16-second event
e. Scroll and select Print (Laser Printer Required)
f. Select Main Menu
(quick key) to return to the main display
Note: The waveform length printed are determined by the setting of Recording
Length from Main Menu→Alarm Setup→Others on the T1 bedside monitor.
DPM Central Station Interface: Event storage and printing length on the
T1 bedside monitor and DPM Central Station are independent.
Panorama Central Station Interface: Event storage and printing length on the
T1 bedside monitor and Panorama Central Station are independent.
Full Disclosure
The T1 monitor has the ability to store configured waveforms and associated
numeric information collected for a configured period.
To adjust waveforms to be stored for a patient:
a. Scroll and select Review >> from Main Menu
(quick key)
b. Select Full Disclosure tab
c. Scroll and select Save Waves >>
d. A
in the waveform box indicates waveform is selected
e. Select Confirm to return to the Full Disclosure tab
f. Select Main Menu
(quick key) or to return to the main display
Note: Full Disclosure allows the clinician to view selected, saved waveforms. It
is for viewing purposes only and cannot be printed.
