T1 Quick Reference Guide

  • Big Numerics: Up to 4 waveforms and numeric parameters in an

expandable view on the main display

  • ECG 7-Lead Full Screen (5 lead wire set): 7 leads of ECG with numeric

parameters on the main display

  • ECG 12-Lead Full Screen (optional): 12 leads of ECG with numeric

parameters on the main display

c. Select Main Menu

(quick key) or to return to the main display

Note: The first waveform is always an ECG lead and HR is always located in the

first digital tile in the Normal Screen selection.

DPM Central Station Interface: Digital and waveform display selections on the

DPM Central Station are independent of the T1 bedside monitor.

Panorama Central Station Interface: Digital and waveform display selections

on the Panorama Central Station, WorkStation, and ViewStation are

independent of the T1 bedside monitor.

HISTORY

Tabular Trends

To display Tabular trends for a patient on the T1 monitor:

a. Scroll and select Review >> from Main Menu

(quick key)

b. Select Tabular Trends tab

c. Scroll and select Trend Group to specify trend category or select Custom

for user defined parameters to be displayed

d. Scroll and select Interval to specify the time interval tabular trends are to

be displayed

e. Select

to return to Tabular Trends

f. Select Main Menu

(quick key) to return to the main display

To print a patient's Tabular (List) trends on the T1 (Laser Printer Required):

a. Scroll and select Review >> from Main Menu

(quick key)

b. Select Tabular Trends tab

c. Scroll and select Print and confirm specified time period

d. Select Print

e. Select Main Menu

(quick key) to return to the main display
