VS 8/VS 8A Vital Signs Monitor Operator’s Manual 9 - 9
9.7.4 Performing Sequence Measurement
To perform sequence measurement, follow this procedure:
1. Prepare the patient and place the cuff as instructed in 9.6 Preparing for NIBP
Measurement.
2. Select a workflow under Continuous Monitoring.
3. Select to set the patient position and measurement site.
4. Select the NIBP numeric area to enter the NIBP dialog.
5. Select Sequence tab to set the duration and interval of phases in the sequence.For
details, see 9.8.5 Setting NIBP Sequence.
6. Select Setup tab, set Interval to Sequence.
7. Set Start Mode to Interval.
8. Select Start NIBP.
9.8 Changing NIBP Settings
9.8.1 Setting the NIBP Alarm Properties
In Continuous Monitoring mode, you can set the NIBP alarm properties. Follow this
procedure:
1. Select the NIBP numeric area to enter the NIBP dialog.
2. Select the Alarm tab.
3. Enter the password if required. For more information, refer to 16.3.3 Selecting
Password for Changing Alarm settings.
4. Set alarm properties as desired.
9.8.2 Setting the NIBP Interval
For auto NIBP measurement, you need to set the interval between two times of NIBP
measurement. In Continuous Monitoring mode, you can set the NIBP interval. Follow
this procedure:
1. Select the NIBP numeric area to enter the NIBP dialog Setup tab.
2. Set Interval. Selecting Manual switches to manual mode.
9.8.3 Selecting NIBP Start Mode
Start mode defines how NIBP auto mode works. In Continuous Monitoring mode, you
can set the start mode. Follow this procedure:
1. Select the NIBP numeric area to enter the NIBP dialog.
2. Set Start Mode.
9 - 10 VS 8/VS 8A Vital Signs Monitor Operator’s Manual
Clock: after the first measurement, the monitor automatically synchronizes
NIBP automatic measurement with the real time clock. For example, if
Interval is set to 20 min, and you start NIBP auto measurement at 14: 03, the
next measurement will be taken at 14: 20, and then at 14:40, 15:00, and so
on.
Interval: after the first measurement, the monitor automatically repeats
measurement at set interval. For example, if Interval is set to 20 min, and
you start NIBP auto measurement at 14:03, the next measurement will be
taken at 14:23, and then at 14:43, 15:03, and so on.
9.8.4 Enabling the NIBP End Tone
The monitor can issue a reminder tone at the completion of NIBP measurement. The
NIBP End Tone is off by default. You can switch on the NIBP tone in workflow setup
dialog. After setting, every time you switch to the workflow, NIBP End Tone is switched
on.
You can also switch on the NIBP end tone in the NIBP dialog. To do so, follow this
procedure:
1. In Continuous Monitoring mode, select the NIBP numeric area to enter the NIBP
dialog. In Spot Check mode, select the Main Menu quick key from the
Parameters column select Setup select NIBP.
2. Switch on NIBP End Tone.
9.8.5 Setting NIBP Sequence
In Continuous Monitoring mode, you can set NIBP sequence. NIBP sequence
measurement can have up to five phases: A, B, C, D, and E. The duration and interval of
each phase can be set individually.
To set NIBP sequence, follow this procedure:
1. Select the NIBP numeric area to enter the NIBP dialog.
2. Select the Sequence tab.
3. Set Duration and Interval of each phase.
9.8.6 Setting the NIBP Display Format
To set the NIBP display format, follow this procedure:
1. In Continuous Monitoring mode, select the NIBP numeric area to enter the NIBP
dialog. In Spot Check mode, select the Main Menu quick key from the
Parameters column select Setup select NIBP.
2. Select the Setup tab.
3. Set Display Format.
