VS 8/VS 8A Vital Signs Monitor Operator’s Manual 9 - 17
2. Under Evaluation Criterion, select to edit an existing criterion or Add Crite-
rion to create a new one.
3. Set the Parameter, Type, Threshold, and select With Symptoms to set whether
to include symptoms in the criterion.
4. Select Save.
9.11 Assisting Venous Puncture
You can use the NIBP cuff to cause sub-diastolic pressure to block the venous blood
vessel and therefore help venous puncture. To assist venous puncture, follow this
procedure:
1. In Continuous Monitoring mode, select the NIBP numeric area to enter the NIBP
dialog. In Spot Check mode, select the Main Menu quick key → from the
Parameters column select Setup → select NIBP.
2. Set Venipuncture Pressure.
3. Select Venipuncture at the bottom of the dialog.
4. Puncture vein and draw blood sample.
5. Select Venipuncture again to deflate the cuff. If the cuff is not manually deflated,
the cuff automatically deflates after a fixed period of time (170 seconds for adult
and pediatric patient, 85 seconds for neonatal patient).
During venous puncture, pay attention to the cuff pressure and the remaining time
displayed in the NIBP numerics area.
• This function is not available on VS 8A monitors.
9.12 NIBP Troubleshooting
This section lists the problems that might occur. If you encounter the problems when
using the equipment or accessories, check the table below before requesting for
services. If the problem persists, contact your service personnel.
9 - 18 VS 8/VS 8A Vital Signs Monitor Operator’s Manual
Problem Solution
Cannot see NIBP
numeric area on the
main screen
Check that the NIBP
is set to display in the Edit Workflow menu.
For more information, see 3.9.1.2 Setting the Screen Layout.
