6-3
6.3.2
Removing the Rec
order
Unscrew the two M3×6 screws and pull the clamps as indicated to remove the recorder
.
Then disconnect the cable.
NOTE
The recorder can be disassembled separately
.
6.3.3
Separating the F
ront and Rear Half of the Monitor
1.
Lay the monitor on a table as show
n belo
w. Unscrew the f
our M3 screws.
Clamps
To Purchase, Visit
Avobus.com
or call
1-800-674-3655
48
50
