6-8
6.3.6
Removing the Par
ameter B
oard (SpO
2
Optional) and P
ower
Management Board
1.
Unscrew the three screws and remove the po
wer management board assembly
from the main bracket assembly
.
2.
Unscrew the two M3 screws and remove the parameter board from the pow
er
management board assembly
.
P
arameter Boar
d
2 M3 screws
53
55
