6-19
6.4.8
Removing the K
eypad
Unplug the encoder cable and unscr
ew the
three PT3×8 screws indicated below. Remov
e
the keypad.
6.4.9
Removing the Enc
oder
Pull the knob off the encoder shaft. Remove th
e retaining nut.
Then remove the encoder
.
6.4.10
Removing the Alarm Lamp
Unscrew the fo
ur PT2×6 screws indicated below and remove the alarm lamp board and
alarm lamp.
