6-18
6.4.6
Removing the
T
ouchscreen
Unscrew the seven PT3×8 screws as indicated below
. R
emove the touchscreen assembly
and then the touchscreen.
6.4.7
Disassembling the Display
Unscrew the fo
ur M3×6 screws indicated below to remove the screen.
SD card
T
ouchscreen
To Purchase, Visit
Avobus.com
or call
1-800-674-3655
