7 Parts
7.1 Introduction
This section contains the exploded views and parts lists of the main unit to identify the
parts during disassembly of the monitor and replacing the parts.
This manual is based on a fully loaded configuration. Your equipment may not contain all
options and therefore may not be appear the same as the unit in this manual.
NOTE
For parts in the Parts List below that contain two part numbers, the first part
number is for patient monitors built with one version of plastic material, the
second part number is for patient monitors built with another version of
plastic material. The way to distinguish which material your monitor is built
from is if it contains the symbol
.
7.2 Main Unit
7.2.1 Exploded View
To Next Page
