6-14
6.4.2
Removing the 2.4G
Wi-F
i Module (Optional, Only A
vailable for
Ac
cutorr 7)
1.
Remove the two antennas on the front panel from the slots as shown below:
2.
Remove the antennas fr
om the W
i-Fi module PCBA.
3.
Push the clamps aside to remov
e the Wi-F
i module.
Clamps
Antenna
Antenna
