7-7
7.1.4 Display Assembly
7.1.4.1 Exploded View
7.1.4.2 Parts List
Note: The P/N of this assembly is 0621-30-69442.
S/N P/N Description Qty
1 0000-10-11020 Inverter DC/AC12VDC/500Vrms 6mA 1
2 7000-20-24417 Insulating strip for backlight board 1
3 0010-10-12357 LCD display TFT 10.4" 800*6003.3V 1
4 0621-30-69351 Flowmeter control board (configured with three flowtubes) 1
5 M04-051140--- Cross recessed small pan head screw assembly GB/T9074.8
M3X8 rustproof nickel plating
4
6 0621-20-69564 M2X15 bolt 4
7 0621-20-69473 Display fixture 1
8 0621-30-78552 Throttling device (O2, N2O and AIR) 1
9 M04-000104--- Single coil spring lock washer, normal type GB/T93-1987 3
rustproof nickel plating
6
10 M04-002405--- Cross recess head screw GB/T818-2000 M2X6 rustproof
nickel plating
10
11 M04-000505--- Cross recess head screw GB/T818-2000 M3X20 rustproof
nickel plating
6
