Mindray WATO EX-55 - Auxiliary O2 Supply Assembly

7-27
12
M07-00126S---
Gas pressure switch, which gives an alarm when pressure
drops 32 PSI
1
13 M04-051026--- Hexagon socket cap head screw M3X10 2
14 m6q-020030--- Valve, regulator 11-990-196 3
15 0621-20-78627 AIR pipe tail fitting 1
16 0621-20-78621 O2 pipe tail fitting 1
17 M6Q-030015--- Connector, straight connector 3175-06-10 2
18 M04-000104--- Spring washer GB93 3 14
19 M04-051093--- Hexagon socket cap head screw M3X12 12
20 0621-20-78624 N2O pipe tail fitting 1
21 0611-30-67605 Pressure relief valve 37.9 3
22 M6Q-020010--- Valve, check valve AKH08A-02S 3
23 M6M-010016--- Seal, O-ring 23.60X2.65 silicone A70 red 3
24 0621-20-78623 N2O pipe support 1
25 M04-051141--- Small pan head combination screw M4X8 2
26 M6M-010021--- Seal, O-ring16.00X2.00 EPT A70 black 3
27 0611-20-45435 Compression spring 3
28 0611-20-45597 N2O pipe connector 1
7.1.19 Auxiliary O2 Supply Assembly
7.1.19.1 Exploded View
