Minuteman E24 - 4.2 Squeegee Adjustment (Version Two)

4.2 Squeegee Adjustment
V
ersion Two
4.2 Squeegee Adjustment
Correct squeegee adjustment is prerequisite for optimal suction results.
Before ad
j
ustment first check the
p
itch of the s
q
uee
g
ee and re-ad
j
ust if re
q
uired.
jpqg
jq
1. Place machine on level ground.
2. Loosen the two bolts, located on each side (Fig 5/2A) with the squeegee attached
while holding another wrench on the location shown on Fig 5/2B. Adjust squeegee
rubbers so that the
y
are
p
arallel to the floor
,
b
y
turnin
g
the lon
g
ad
j
ustment shaft on the
yp ,y g gj
right side with an open end or adjustable wrench (Fig 5/2B). Adjust until the rear
squeegee blade folds equally accross the entire length, while moving the machine
slightly forward.
3. Ti
g
hten the two bolts on the ends while holdin
g
the center shaft with the wrench.
gg
4. Turn machine on, lower squeegee and check drying pattern.
Fig 5/2BFig 5/2A
15
