5.1 Brush Motor Information
51
Brush Motors
5
.
1
Brush
Motors
The brush motors are switched on and off by a micro-switch located at the rear at the brush head
lift-out system. This switch is realised as NO (normally open) switch. To attain safe function of the
brush motors
,
correct ad
j
ustment of this switch is re
q
uired.
,j q
Electric connection of the switch is realised at the central control at A1.X9:4 + 10.
Maximum current consumption of the brush motors (in practical use) must not exceed 30A per
motor on the 26 and 30“ disk brush decks. The maximum amperage for the 33“ disk decks is 40A.
Lower settings are recommended for longer motor life, run time and traction.
When checking the carbon brushes make sure that the scroll spring is pressing the carbon brush
against the commutator, does not contact the guide and that distance to carbon brush guide is
sufficient.
Replace the carbon brushes, if required.
