Minuteman E24 - 4.4 Squeegee Wheel Adjustment

4.4 Squeegee Wheel Adjustment
4.4 Note: When adjusting the wheel height, there should always be 5 washers on each wheel
assembly position # 15 in order fully tighten bolts. Move washers from the top to the bottom of
the bracket or visa versa when making adjustments The caster controls the pressure on the
Pos 1 – Hexagon screw M8x25 A2
PN 01059530
the
bracket
or
visa
versa
when
making
adjustments
.
The
caster
controls
the
pressure
on
the
squeegee blade.
Pos 5 – Hexagon screw M8x16 A2
PN 01071740
Pos 6 – Washer B8,4
PN 00101550
Pos 7 – fixed Roller
PN 01077810
Pos 8 – Angle with fixed roller, complet
PN 01079070
Fi
g
. 5/3
PN
01079070
Pos 15 – Distance Washer
PN 01079080
g
