Minuteman E24 - 6.4 Brush Head (Cylindrical)

6.4 Brush Head (Cylindrical)
6.4 Electric Connections
• Connect the brush motors of the cylindrical broom head in accordance with
the electric diagrams. Find the assignment of connecting stud of the motors
listed in the below table. Then check the correct direction of brush motor
tti
ro
t
a
ti
on.
• The left-hand motor seen in direction of travel is M3, the right-hand one is
M4.
M3 M4
Motor connection
Cyl. brush head
Cable
Harness
Connectors
at the motor -M3/4
Stud bolt above
Connection N
Stud bolt below
Connection P
Connection
N
