Minuteman E24 - Page 81

1177-02
001 / Ri. / 12.12.07 [ 002 / kupe / 12.12.07 ]date of plot:
-A1 controller E24 / E26 /1.2090541483
-A2 control panel /1.2690487216
-A3 key board /1.2990487232
-G1 battery /1.3
-G2 on-board-charger /1.397097679
-K1 main contactor /1.990529942
-M1 drive motor /1.3290539750
-M1.S1 thermal switch drive motor /1.33to -M1
-M1.S2 brake switch drive motor /1.37to -M1
-M1.Y1 brake drive motor /1.35to -M1
-M2 suction motor /1.3797096200
-M3 conical brush motor left 850 /1.3190507484
-M3.S1 thermal switch brush motor left /1.33to -M3
-M4 conical brush motor right 850 /1.3190507484
-M4.S1 thermal switch brush motor right /1.33to -M4
-M7 water pump /1.897047310
-R1 speed giver /1.3497100416
-S1 key switch /1.2690323437
-S3 suction on /1.3790306002
-S4 brush on /1.3590306002
-S5 dead man switch left /1.2890520446
-S6 direction switch /1.3090516147
-S7 dead man switch right /1.2690520446
-S11 spray tool on (OPTION spray tool) /1.1290224650
-X1 battery connector 160A /1.2
-X8 connector 2 poles /1.37
-X9 connector 2 poles /1.37
-X10 connector 2 poles /1.33
-X12 connector 2 poles /1.34
-X17 connector 4 poles /1.35
-X18 connector 1 poles /1.8
-X19 connector 1 poles /1.9
-X24 connector 3 poles /1.4
-X25 connector 1 poles /1.1
-X26 connector 1 poles /1.3
-X27 connector 1 pole /1.13
-X31 connector 2 poles /1.18
-X32 connector 3 poles /1.33
-X101 connection virtual ground at chassis /1.13
12.12.2007
-X102 connection virtual ground at direction switch /1.13
-Y1 water valve /1.1290435595
page
pa.
12.12.07 Ri.
2007
0
A3
Eingeführt lt.
circuit diagram
91026898
91026898
E 33 / Ph 35
ref. designation pathpart no
ref. designation pathpart no
modified no. date
date
drawn by
checked
name
2
3
09.11.
=
+
D-23840 Bad Oldesloe
no.
name
indemnity for:
modified no.:
kupe
Hako-Werke GmbH
no. available
