Table 4
TESTS ON PCB MIR040 WITHOUT OXIMETER
Test
Procedure
Test method
Instrument
Expected result
Battery pack connection to the PCB
Check correct procedure described in point 4.3.2
Visual
\
The battery pack must be completely connected and the
cable must be bended as shown in image at point 4.3.2
Check display for scratches
Check the display
Visual
\
No scratches or creases must be present
Check display position
Check correct positioning of the display the upper casing
Visual
\
The display perimeter must be perfectly adjacent to the
housing on the upper casing
Check the display flat cable
Check display flat cables and position of connectors on
the PCB
Visual
\
The flat cables don’t must be extremely bended and the
connectors must be inserted in the corrected way
Check position of PCB MIR040 with the
middle casing
Check that the PCB is placed correctly
Visual/
Quantitative
\
The teeth on the orange casing must be inserted in the
special housings on the PCB
Check device is closed properly
Check the coupling of the three parts of casing
Visual/
Quantitative
\
Upper, middle and lower casing, after the closing of the
device, must not have open points i the entire perimeter
