Appendix C: Module Specifications And Features
38
Appendix C: Module Specifications And Features
FA-201 Fire Alarm Control Panel
General
• One supervised Class B (Style B) initiating circuit; configurable (normal or verified). [Compatibility ID “A”]
Power Limited: 26VDC, 3 mA standby, 1.5Vp-p ripple, 50 mA max. (alarm)
• Two Class A/B (Style Y/Z) indicating circuits; configurable as strobes or audibles.
Power limited: 24 VDC unfiltered
• 1.7 A @ 49°C per circuit (2.4 a total)
• Initiating circuit disconnect switch.
• Optional DACT or city tie adder module.
• Optional RM-204 / RM-208 Relay Module.
• Resettable four-wire smoke supply.
Power Limited: 28VDC, 100mA max, 1.5Vp-p ripple
• Aux power supply.
Power limited: 24VDC, 300mA max, unfiltered for RTI or remote annunciators
• 1 RTI Interface for connection to an RTI Remote Trouble Indicator.
• Auxiliary relays (resistive loads):
Common Alarm: Form C, 1Amp, 28VDC
Common Trouble: Form C, 1Amp, 28VDC
• Micro-controller based design.
• DIP switch configurable.
• Walktest function.
Electrical ratings
• AC Line Voltage: 120V 60 Hz / 240V 50 Hz
2A / 1A
• Two amps (primary, transformer inline fuse)
• Power supply ratings: 2.75 amps. max. (secondary)
• For indicating circuits: 24VDC unfiltered 2.40 amps. max.
• Battery: 24VDC, gel-cell/sealed lead-acid
• Charging capability: 4 to 12 AH batteries
• Fuse on main board: 10 Amps.
• Current consumption: standby: 110 mA
alarm: 220 mA
FA-202 Fire Alarm Control Panel
Same as FA-201, plus ...
• Two supervised Class B (Style B) or 1 Class A (Style D) initiating circuits; configurable (normal or verified).
[Compatibility ID “A”]
