15
4.0 Start Up
Before start up, disconnect the network cable.
When the system is plugged in and the batteries are connected, the front display shows the
following message:
If the system is unconfigured, then the third line shows Confg to FactoryDflt.
The fourth line is the firmware version.
Let the system initialize for approximately one to two minutes.
Download the configuration at each Node using a laptop computer and Mircom’s MGC-4000
Configurator. Once all the Nodes have been downloaded, connect the network and select the
Network Restart (see page 56) at the CACF (Central Alarm and Control Facilities) or main
node.
If there is an alarm, supervisory, trouble, or monitor condition in the system, pressing the
appropriate queue button and holding displays information on the cause of the alarm,
supervisory, trouble, or monitor device activation.
Note: To display the configuration software version, press , then hold .
Initial system self
checks in process...
v1.6.2
