Appendix E: DIP Switch Settings Summary
RAX-LCD
ADDR SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8
33 OFFONONONONOFFON
Put in "OFF" position for firmware restore to defaults during power up. At all other times
put in "ON" state.
34 ONOFFONONONOFFON
35 OFF OFF ON ON ON OFF ON
36 ON ON OFF ON ON OFF ON
37 OFF ON OFF ON ON OFF ON
38 ON OFF OFF ON ON OFF ON
39 OFFOFFOFFONONOFFON
40 ON ON ON OFF ON OFF ON
41 OFF ON ON OFF ON OFF ON
42 ON OFF ON OFF ON OFF ON
43 OFF OFF ON OFF ON OFF ON
44 ON ON OFF OFF ON OFF ON
45 OFFON OFFOFFON OFFON
46 ON OFF OFF OFF ON OFF ON
47 OFF OFF OFF OFF ON OFF ON
48 ON ON ON ON OFF OFF ON
49 OFFONONONOFFOFFON
50 ON OFF ON ON OFF OFF ON
51 OFF OFF ON ON OFF OFF ON
52 ON ON OFF ON OFF OFF ON
53 OFF ON OFF ON OFF OFF ON
54 ON OFF OFF ON OFF OFF ON
55 OFF OFF OFF ON OFF OFF ON
56 ON ON ON OFF OFF OFF ON
57 OFF ON ON OFF OFF OFF ON
58 ON OFF ON OFF OFF OFF ON
59 OFF OFF ON OFF OFF OFF ON
60 ON ON OFF OFF OFF OFF ON
61 OFFON OFFOFFOFFOFFON
62 ON OFF OFF OFF OFF OFF ON
63 OFF OFF OFF OFF OFF OFF ON
RAM-208 or RAM-216
ADDR SW1-1 SW1-2 SW1-3 SW1-4 JP-1
33 ON OFF OFF OFF JUMPER ON Pins 2&3 when
used with FX-2000 version
2.X.X or higher(16 bit
checksum). JUMPER ON
Pins 1&2 when used with FX-
2000 version 0.X.X(8 bit
checksum). Firmware of 208/
216 must be 1.0.6 or higher to
accommodate 16 bit
34 OFF ON OFF OFF
35 ON ON OFF OFF
36 OFF OFF ON OFF
37 ON OFF ON OFF
38 OFF ON ON OFF
39 ON ON ON OFF
40 OFFOFFOFFON
