Appendix A: Specifications
12.0 Appendix A: Specifications
12.1 FX-2003-6DS and FX-2003-6DS-16LED Specifications
Table 21 FX-2003-6DS and FX-2003-6DS-16LED Specifications
FX-2003-6DS and FX-2003-6DS-16LED Chassis
Analog Loop One Analog Loop capable of monitoring 99 Sensors and 99 Modules
Line voltage 22 VDC, 400 mA max, max loop resistance 40
NAC Circuits 4 Style Y or Z (Class B or A) NAC circuits, configured as strobes or audibles. Terminals
are labelled "IND".
Rating Power limited / 24 VDC unfiltered, 1.7 A @ 49°C per circuit
Max power allowed 5A
Aux Power Supply for
remote annunciators
Terminals are labelled "AUX PWR".
Rating Power Limited 24 VDC unfiltered, 1.7 A @ 49°C
Resettable 4-Wire
Smoke Supply
Terminals are labelled "4-WIRE".
Rating 22 VDC, 400 mA max., 5mV ripple
RS-485 port For Remote Annunciators or interface to Audio Systems. Terminals are labelled "RS-485".
Rating Power limited to 300 mA.
Auxiliary relays
(resistive loads)
Terminals are labelled "ALARM, TROUBLE, SUPV".
Alarm/Supv/Trouble Must be connected to a Listed Power Limited Source of
Supply. Form C, 1 Amp, 28 VDC
Electrical ratings AC Line Voltage 120V 60Hz / 240V, 50Hz
2 Amps / 1 Amp (primary)
Power Supply ratings 12 Amps. Max. (secondary)
Battery Type 24VDC, Gel-Cell/Sealed Lead-Acid
Charging capability 10-24 AH batteries
Charging current 3A maximum
Current Consumption standby: 230 mA
alarm: 380 mA
Other Displays (incl LCD) and Controls for all Common Functions, and 16 Zone Displays.
Micro-controller based design.
Fully Configurable with PC software.
Full walk test function.
