Configuration
Version 1.1 Telephone Access System User Guide 15 (42)
LT-968 Copyright 2012
2.7 Main Door DTMF Setup
The main door DTMF setup feature allows the resident to use their telephone
touch tone keypad to open the main door.
To set up the main door DTMF
Figure 4. Main Door DTMF Setup
You have successfully set the main door DTMF. The display now returns to the
configuration menu.
1. Select Configuration Menu, System Option.
2. Press (scroll up) or (scroll down) to find
“Main Door DTMF”.
3. Press when the arrow is beside “Main Door
DTMF”, the display enters Main Door DTMF setup.
4. Select any digit between 1 to 9, * or #, and press .
This selection becomes the designated (touch tone)
number or symbol that opens the main door. The
factory default is “9”.
5. Press to save and continue.
