Configuration
Version 1.1 Telephone Access System User Guide 17 (42)
LT-968 Copyright 2012
2.9 DTMF Sensitivity setup
The DTMF sensitivity feature allows the resident to change how sensitive the
TX3 unit is to receiving DTMF signals. DTMF sensitivity can be set from 1 to 8.
A sensitivity of 1 indicates the lowest sensitivity while 8 is the highest sensitivity.
The default sensitivity is 5.
To set the DTMF
sensitivity
Figure 6. DTMF Sensitivity
You have successfully set the DTMF sensitivity. The display now returns to the
configuration menu.
1. Press (scroll up) or (scroll down) to find
“DTMF Sensitivit”.
2. Press when the arrow is beside “DTMF Sensitivit”.
The display enters DTMF Sensitivity setup.
3. Press (scroll up) or (scroll down) to select
the sensitivity level.
4. Press to save and continue.
