16 (42) Telephone Access System User Guide Version 1.1
LT-968 Copyright 2012
Configuration
2.8 Auxiliary Door DTMF setup
The auxiliary door DTMF setup feature allows the resident to use their telephone
touch tone keypad to open the auxiliary door.
To set up the auxiliary door DTMF
Figure 5. Auxiliary Door DTMF Setup
You have successfully set the auxiliary door DTMF. The display now returns to
the configuration menu.
If you have not setup Main Door DTMF,
1. Press (scroll up) or (scroll down) to
find “Aux Door DTMF”.
2. Press when the arrow is beside “Aux Door
DTMF”. The display enters Aux Door DTMF setup.
3. Select any digit between 1 to 9, * or #, and press .
This selection becomes the designated (touch tone)
number or symbol that opens the auxiliary door. The
factory default is “6”.
DO NOT select “4”, this is used to refuse entry or
disconnect.
4. Press to save and continue.
