EMPTY KEY
You can set a softkey to force a blank entry on the IP phone display for a specific key. You do
this by setting the softkey to Empty. The keys are added in order (from key 1 to key 18 [bottom]
or key 20 [top]) after any hard-coded keys have been added. If a particular key is not defined,
it is ignored.
CONFIGURING AN EMPTY KEY USING THE MITEL WEB UI
1. Click on Operation > Softkeys and XML.
or
Click on Operation > Expansion Module <N>.
Softkeys
2. Select from Key 1 through Key 20 on the Top keys.
or
Select from Key 1 through Key 18 on the Bottom keys.
3. In the Type field, select Empty.
4. In the state fields, check (enable) or uncheck (disable) the states you want to apply to this
softkey.
Expansion Module Keys
5. Select from Key 1 through Key 16 (M680i) or Key 84 (M685i).
6. In the Type field, select Empty.
7. Click Save Settings.
MITEL WEB UI
