Mitel 6869i - Callers List Key Configuration

Configuring Softkeys
121
CONFERENCE KEY
Using the Mitel Web UI, you can assign a Conference key to any key on the top or bottom
keys on the phone.
CONFIGURING A CONFERENCE KEY USING THE MITEL WEB UI
1. Click on Operation > Softkeys and XML.
or
Click on Operation > Expansion Module <N>.
Softkeys
2. Select from Key 1 through Key 44 on the Top keys.
or
Select from Key 1 through Key 24 on the Bottom keys.
3. In the Type field, select Conference.
4. In the Label field, enter a label to apply to this key.
5. In the state fields, check (enable) or uncheck (disable) the states you want to apply to this
softkey.
Expansion Module Keys
6. Select from Key 1 through Key 16 (M680i) or Key 84 (M685i).
7. In the Type field, select Conference.
8. Click Save Settings.
Note: For more information about conferencing, see “Conferencing Calls” on page 145.
MITEL WEB UI
