164
6 OPTIONS AND PERIPHERAL EQUIPMENT
6.2 Regenerative option
Selection of the regenerative option [WG]
A regenerative option for a horizontal axis can be selected with the rough calculation shown in this section. To select a
regenerative option precisely, use the capacity selection software.
Rotary servo motor
■Regenerative energy calculation
V: Feed speed of moving part [mm/min]
N: Servo motor speed (N = V/S) [r/min]
S: Travel distance per servo motor revolution (S = PB) [mm/rev]
P
B
: Ball screw lead [mm]
L
B
: Ball screw length [mm]
D
B
: Ball screw diameter [mm]
W
L
: Moving part mass [kg]
F
C
: Load antidrag setting [N]
T
L
: Load torque converted into equivalent value on servo motor shaft [N•m]
: Drive system efficiency
: Friction coefficient
JL: Load moment of inertia converted into equivalent value on servo motor shaft [kg•cm
2
]
JM: Moment of inertia of the servo motor [kg•cm
2
]
: Pi constant
g: Gravitational acceleration [m/s
2
]
N
V
W
L
F
C
(2)
(1)
V
(3)
(4)
(6)
(5) (7)
(8)
t
psa1
t
1
t
psd1
t
2
t
psa2
t
3
t
4
t
psd2
Servo motor
Feed speed of moving part
Forward
rotation
Time
Moving part
Reverse
rotation
