172
6 OPTIONS AND PERIPHERAL EQUIPMENT
6.2 Regenerative option
MR-RB50/MR-RB5N/MR-RB51
[Unit: mm]
• Terminal block
Screw size: M4
Tightening torque: 1.2 [N•m]
• Mounting screw
Screw size: M6
Tightening torque: 5.4 [N•m]
Regenerative option Variable dimensions Mass [kg]
A B
MR-RB50 17 217 5.6
MR-RB5N
MR-RB51
G4 G3 C P
2.3
49 82.5
200
A
B 8120
108
12
7
350
162.5
12.5
12.5
82.5133
162.5
Screw for mounting cooling fan
(2-M3 screw) opposite side
7×14
slotted
hole
Intake
Approx. 30
P
C
G3
G4
