3 SPECIFICATIONS
3.4 Function List
3.4 Function List
This section lists the functions of I/O modules.
: Available, : Not available
Item Description Function availability Reference
Input
module
Output
module
I/O
combined
module
Input response time setting
function
Prevents an incorrect input due to noise by setting
the response time required for the module to
recognize an actual input as the X signal.
 Page 155
Input Response
Time Setting
Function
Output HOLD/CLEAR
setting function
Sets whether to hold or clear the last output value
when the I/O module is disconnected from data link,
when the CPU module operating status is STOP, or
when the CPU module operation is suspended by an
error.
 Page 156
Output HOLD/
CLEAR Setting
Function
CC-Link IE TSN Network
synchronous
communication function
Performs I/O with a synchronization cycle of the
master station that supports the CC-Link IE TSN
Network synchronous communication function.
 Page 157 CC-
Link IE TSN
Network
Synchronous
Communication
Function
Communication speed
setting function
Sets the communication speed.  Page 175
Communication
Speed Setting
Function
Output ON/OFF information
hold function
Checks whether the output has been turned on or
off.
 Page 176
Output ON/OFF
Information Hold
Function
Protection function The transistor output module and the I/O combined
module (transistor output part) have the overload
protection function and the overheat protection
function.
 Page 177
Protection Function
Module power supply
voltage drop detection
function
Detects a voltage drop of the module power supply.  Page 178
Module Power
Supply Voltage
Drop Detection
Function
External power supply
monitoring function
Monitors the ON/OFF status of the external power
supply.
 Page 178
External Power
Supply Monitoring
Function
Firmware update function Updates the firmware of the I/O module via CC-Link
IE TSN.
 Page 179
Firmware Update
Function
CPU module in STOP
external output test function
Turns on or off the output of a remote device at any
desired time while the CPU module is in STOP.
For details, refer to descriptions of the remote device
test in the following manual.
User's manual for the master station used
 
