Appendix 2 Remote Register
Appendix 2 Remote Register
List of remote registers
This section lists remote registers for a master/local module.
The remote registers shown are the examples with the start of remote registers of the I/O module assigned to the device
number of RWr0 and RWw0.
Remote register (RWr) is the information input from the I/O module to the master/local module.
Remote register (RWw) is the information output from the master/local module to the I/O module.
Input module (16-point module)
■Remote register (RWr)
*1 The area is used for the system.
■Remote register (RWw)
*1 The area is used for the system.
Device number Name
CC-Link IE TSN Network synchronous communication function
Not used Synchronous X/Y control
mode
Synchronization cycle
timing control mode
Set time synchronization
control mode
RWr0 Use prohibited Use prohibited Use prohibited Use prohibited
RWr1 Error code Error code Error code Error code
RWr2 Function selection status area Function selection status area Function selection status area Function selection status area
RWr3 Use prohibited Use prohibited Use prohibited
*1
Use prohibited
*1
RWr4 Use prohibited Use prohibited Use prohibited Input ON/OFF information X0 to
XF
RWr5 to RWrF Use prohibited Use prohibited Use prohibited Use prohibited
RWr10, RWr11 Use prohibited Use prohibited Synchronization input timing
information X0 OFF to ON
Input time information X0
RWr12, RWr13 Use prohibited Use prohibited Synchronization input timing
information X0 ON to OFF

RWr4C, RWr4D Use prohibited Use prohibited Synchronization input timing
information XF OFF to ON
Input time information XF
RWr4E, RWr4F Use prohibited Use prohibited Synchronization input timing
information XF ON to OFF
Device number Name
CC-Link IE TSN Network synchronous communication function
Not used Synchronous X/Y control
mode
Synchronization cycle
timing control mode
Set time synchronization
control mode
RWw0 Module operation area Module operation area Module operation area Module operation area
RWw1 Use prohibited Use prohibited Use prohibited Use prohibited
RWw2 Use prohibited Use prohibited Use prohibited Use prohibited
RWw3 Use prohibited Use prohibited Use prohibited
*1
Use prohibited
*1
RWw4 Use prohibited Use prohibited Use prohibited ON/OFF selection flag X0 to XF
RWw5 to RWw4F Use prohibited Use prohibited Use prohibited Use prohibited
