Series Controllers - Getting Started 6
26
ENG
ProgClear - Deletes everything in program memory, programs and data!
Others - Gives more Options for a Version Check, Password Protection, Summer Time Change Schedule,
Modem Initialization, and Menu Key operation.
Table 6.1:Key Number and Basic Operation
Key
number
Main Key Function
K01 OK: acceptance of data entry, menu options, program choices
K02 ESC: cancel current operation, move to higher screen or menu
K03 "+": connect function blocks, move to higher numbered blocks, increment values
K04 “-”: disconnect function blocks, move to lower numbered blocks, decrement values
K05 Up ( ): scroll to higher number numbered items (keys, FB, Inputs, Outputs, etc.)
K06
Down ( ): scroll to lower numbered items (keys, FB, Inputs, Outputs, etc.)
K07
Right ( ): move to the right on the LCD display, FB program or Jump command
K08
Left ( ): move to the left on the LCD display, FB program or Jump command
Table 6.2: Function Block Description
Function Block Byte Description
AND 19 Output On when all Inputs are On, Unused inputs considered On
OR 19 Output On when at least one input On, Unused inputs considered Off
XOR 13 Exclusive OR; Output On when only One of Two Inputs is On
NAND 19 Not AND; Output Off only when all Inputs On, Unused inputs considered On
