Indoor unit switch setting display (Request code: 162 to 166)
0: OFF 1: ON
SW1, SW2, SW3, SW4, SW5
Display
1 2 3 4 5 6 7 8
0 0 0 0 0 0 0 1 00 80
1 0 0 0 0 0 0 1 00 81
0 1 0 0 0 0 0 1 00 82
1 1 0 0 0 0 0 1 00 83
0 0 1 0 0 0 0 1 00 84
1 0 1 0 0 0 0 1 00 85
0 1 1 0 0 0 0 1 00 86
1 1 1 0 0 0 0 1 00 87
0 0 0 1 0 0 0 1 00 88
1 0 0 1 0 0 0 1 00 89
0 1 0 1 0 0 0 1 00 8A
1 1 0 1 0 0 0 1 00 8B
0 0 1 1 0 0 0 1 00 8C
1 0 1 1 0 0 0 1 00 8D
0 1 1 1 0 0 0 1 00 8E
1 1 1 1 0 0 0 1 00 8F
0 0 0 0 1 0 0 1 00 90
1 0 0 0 1 0 0 1 00 91
0 1 0 0 1 0 0 1 00 92
1 1 0 0 1 0 0 1 00 93
0 0 1 0 1 0 0 1 00 94
1 0 1 0 1 0 0 1 00 95
0 1 1 0 1 0 0 1 00 96
1 1 1 0 1 0 0 1 00 97
0 0 0 1 1 0 0 1 00 98
1 0 0 1 1 0 0 1 00 99
0 1 0 1 1 0 0 1 00 9A
1 1 0 1 1 0 0 1 00 9B
0 0 1 1 1 0 0 1 00 9C
1 0 1 1 1 0 0 1 00 9D
0 1 1 1 1 0 0 1 00 9E
1 1 1 1 1 0 0 1 00 9F
0 0 0 0 0 1 0 1 00 A0
1 0 0 0 0 1 0 1 00 A1
0 1 0 0 0 1 0 1 00 A2
1 1 0 0 0 1 0 1 00 A3
0 0 1 0 0 1 0 1 00 A4
1 0 1 0 0 1 0 1 00 A5
0 1 1 0 0 1 0 1 00 A6
1 1 1 0 0 1 0 1 00 A7
0 0 0 1 0 1 0 1 00 A8
1 0 0 1 0 1 0 1 00 A9
0 1 0 1 0 1 0 1 00 AA
1 1 0
1 0 1 0 1 00 AB
0 0 1 1 0 1 0 1 00 AC
1 0 1 1 0 1 0 1 00 AD
0 1 1 1 0 1 0 1 00 AE
1 1 1 1 0 1 0 1 00 AF
0 0 0 0 1 1 0 1 00 B0
1 0 0 0 1 1 0 1 00 B1
0 1 0 0 1 1 0 1 00 B2
1 1 0 0 1 1 0 1 00 B3
0 0 1 0 1 1 0 1 00 B4
1 0 1 0 1 1 0 1 00 B5
0 1 1 0 1 1 0 1 00 B6
1 1 1 0 1 1 0 1 00 B7
0 0 0 1 1 1 0 1 00 B8
1 0 0 1 1 1 0 1 00 B9
0 1 0 1 1 1 0 1 00 BA
1 1 0 1 1 1 0 1 00 BB
0 0 1 1 1 1 0 1 00 BC
1 0 1 1 1 1 0 1 00 BD
0 1 1 1 1 1 0 1 00 BE
1 1 1 1 1 1 0 1 00 BF
0: OFF
1: ON
SW1, SW2, SW3, SW4, SW5
Display
1 2 3 4 5 6 7 8
0 0 0 0 0 0 1 1 00 C0
1 0 0 0 0 0 1 1 00 C1
0 1 0 0 0 0 1 1 00 C2
1 1 0 0 0 0 1 1 00 C3
0 0 1 0 0 0 1 1 00 C4
1 0 1 0 0 0 1 1 00 C5
0 1 1 0 0 0 1 1 00 C6
1 1 1 0 0 0 1 1 00 C7
0 0 0 1 0 0 1 1 00 C8
1 0 0 1 0 0 1 1 00 C9
0 1 0 1 0 0 1 1 00 CA
1 1 0 1 0 0 1 1 00 CB
0 0 1 1 0 0 1 1 00 CC
1 0 1 1 0 0 1 1 00 CD
0 1 1 1 0 0 1 1 00 CE
1 1 1 1 0 0 1 1 00 CF
0 0 0 0 1 0 1 1 00 D0
1 0 0 0 1 0 1 1 00 D1
0 1 0 0 1 0 1 1 00 D2
1 1 0 0 1 0 1 1 00 D3
0 0 1 0 1 0 1 1 00 D4
1 0 1 0 1 0 1 1 00 D5
0 1 1 0 1 0 1 1 00 D6
1 1 1 0 1 0 1 1 00 D7
0 0 0 1 1 0 1 1 00 D8
1 0 0 1 1 0 1 1 00 D9
0 1 0 1 1 0 1 1 00 DA
1 1 0 1 1 0 1 1 00 DB
0 0 1 1 1 0 1 1 00 DC
1 0 1 1 1 0 1 1 00 DD
0 1 1 1 1 0 1 1 00 DE
1 1 1 1 1 0 1 1 00 DF
0 0 0 0 0 1 1 1 00 E0
1 0 0 0 0 1 1 1 00 E1
0 1 0 0 0 1 1 1 00 E2
1 1 0 0 0 1 1 1 00 E3
0 0 1 0 0 1 1 1 00 E4
1 0 1 0 0 1 1 1 00 E5
0 1 1 0 0 1 1 1 00 E6
1 1 1 0 0 1 1 1 00 E7
0 0 0 1 0 1 1 1 00 E8
1 0 0 1 0 1 1 1 00 E9
0 1 0 1 0 1 1 1 00 EA
1 1 0
1 0 1 1 1 00 EB
0 0 1 1 0 1 1 1 00 EC
1 0 1 1 0 1 1 1 00 ED
0 1 1 1 0 1 1 1 00 EE
1 1 1 1 0 1 1 1 00 EF
0 0 0 0 1 1 1 1 00 F0
1 0 0 0 1 1 1 1 00 F1
0 1 0 0 1 1 1 1 00 F2
1 1 0 0 1 1 1 1 00 F3
0 0 1 0 1 1 1 1 00 F4
1 0 1 0 1 1 1 1 00 F5
0 1 1 0 1 1 1 1 00 F6
1 1 1 0 1 1 1 1 00 F7
0 0 0 1 1 1 1 1 00 F8
1 0 0 1 1 1 1 1 00 F9
0 1 0 1 1 1 1 1 00 F
A
1 1 0 1 1 1 1 1 00 FB
0 0 1 1 1 1 1 1 00 FC
1 0 1 1 1 1 1 1 00 FD
0 1 1 1 1 1 1 1 00 FE
1 1 1 1 1 1 1 1 00 FF
