Output signal display (Request code: 175/553)
PleaserefertoTable2onrelevantwiringdiagramwhilstusingthefollowing.
0: OFF 1: ON
OUT
Display
1 2 3 4 5A 5B 6 7
0 0 0 0 0 0 0 0 xx00
1 0 0 0 0 0 0 0 xx01
0 1 0 0 0 0 0 0 xx02
1 1 0 0 0 0 0 0 xx03
0 0 1 0 0 0 0 0 xx04
1 0 1 0 0 0 0 0 xx05
0 1 1 0 0 0 0 0 xx06
1 1 1 0 0 0 0 0 xx07
0 0 0 1 0 0 0 0 xx08
1 0 0 1 0 0 0 0 xx09
0 1 0 1 0 0 0 0 xx0A
1 1 0 1 0 0 0 0 xx0B
0 0 1 1 0 0 0 0 xx0C
1 0 1 1 0 0 0 0 xx0D
0 1 1 1 0 0 0 0 xx0E
1 1 1 1 0 0 0 0 xx0F
0 0 0 0 1 0 0 0 xx10
1 0 0 0 1 0 0 0 xx11
0 1 0 0 1 0 0 0 xx12
1 1 0 0 1 0 0 0 xx13
0 0 1 0 1 0 0 0 xx14
1 0 1 0 1 0 0 0 xx15
0 1 1 0 1 0 0 0 xx16
1 1 1 0 1 0 0 0 xx17
0 0 0 1 1 0 0 0 xx18
1 0 0 1 1 0 0 0 xx19
0 1 0 1 1 0 0 0 xx1A
1 1 0 1 1 0 0 0 xx1B
0 0 1 1 1 0 0 0 xx1C
1 0 1 1 1 0 0 0 xx1D
0 1 1 1 1 0 0 0 xx1E
1 1 1 1 1 0 0 0 xx1F
0 0 0 0 0 1 0 0 xx20
1 0 0 0 0 1 0 0 xx21
0 1 0 0 0 1 0 0 xx22
1 1 0 0 0 1 0 0 xx23
0 0 1 0 0 1 0 0 xx24
1 0 1 0 0 1 0 0 xx25
0 1 1 0 0 1 0 0 xx26
1 1 1 0 0 1 0 0 xx27
0 0 0 1 0 1 0 0 xx28
1 0 0 1 0 1 0 0 xx29
0 1 0 1 0 1 0 0 xx2A
1 1 0
1 0 1 0 0 xx
2B
0 0 1 1 0 1 0 0 xx2C
1 0 1 1 0 1 0 0 xx2D
0 1 1 1 0 1 0 0 xx2E
1 1 1 1 0 1 0 0 xx2F
0 0 0 0 1 1 0 0 xx30
1 0 0 0 1 1 0 0 xx31
0 1 0 0 1 1 0 0 xx32
1 1 0 0 1 1 0 0 xx33
0 0 1 0 1 1 0 0 xx34
1 0 1 0 1 1 0 0 xx35
0 1 1 0 1 1 0 0 xx36
1 1 1 0 1 1 0 0 xx37
0 0 0 1 1 1 0 0 xx38
1 0 0 1 1 1 0 0 xx39
0 1 0 1 1 1 0 0 xx3A
1 1 0 1 1 1 0 0 xx3B
0 0 1 1 1 1 0 0 xx3C
1 0 1 1 1 1 0 0 xx3D
0 1 1 1 1 1 0 0 xx3E
1 1 1 1 1 1 0 0 xx3F
0: OFF 1: ON
OUT
Display
1 2 3 4 5A 5B 6 7
0 0 0 0 0 0 1 0 xx40
1 0 0 0 0 0 1 0 xx41
0 1 0 0 0 0 1 0 xx42
1 1 0 0 0 0 1 0 xx43
0 0 1 0 0 0 1 0 xx44
1 0 1 0 0 0 1 0 xx45
0 1 1 0 0 0 1 0 xx46
1 1 1 0 0 0 1 0 xx47
0 0 0 1 0 0 1 0 xx48
1 0 0 1 0 0 1 0 xx49
0 1 0 1 0 0 1 0 xx4A
1 1 0 1 0 0 1 0 xx4B
0 0 1 1 0 0 1 0 xx4C
1 0 1 1 0 0 1 0 xx4D
0 1 1 1 0 0 1 0 xx4E
1 1 1 1 0 0 1 0 xx4F
0 0 0 0 1 0 1 0 xx50
1 0 0 0 1 0 1 0 xx51
0 1 0 0 1 0 1 0 xx52
1 1 0 0 1 0 1 0 xx53
0 0 1 0 1 0 1 0 xx54
1 0 1 0 1 0 1 0 xx55
0 1 1 0 1 0 1 0 xx56
1 1 1 0 1 0 1 0 xx57
0 0 0 1 1 0 1 0 xx58
1 0 0 1 1 0 1 0 xx59
0 1 0 1 1 0 1 0 xx5A
1 1 0 1 1 0 1 0 xx5B
0 0 1 1 1 0 1 0 xx5C
1 0 1 1 1 0 1 0 xx5D
0 1 1 1 1 0 1 0 xx5E
1 1 1 1 1 0 1 0 xx5F
0 0 0 0 0 1 1 0 xx60
1 0 0 0 0 1 1 0 xx61
0 1 0 0 0 1 1 0 xx62
1 1 0 0 0 1 1 0 xx63
0 0 1 0 0 1 1 0 xx64
1 0 1 0 0 1 1 0 xx65
0 1 1 0 0 1 1 0 xx66
1 1 1 0 0 1 1 0 xx67
0 0 0 1 0 1 1 0 xx68
1 0 0 1 0 1 1 0 xx69
0 1 0 1 0 1 1 0 xx6A
1 1 0
1 0 1 1 0 xx
6B
0 0 1 1 0 1 1 0 xx6C
1 0 1 1 0 1 1 0 xx6D
0 1 1 1 0 1 1 0 xx6E
1 1 1 1 0 1 1 0 xx6F
0 0 0 0 1 1 1 0 xx70
1 0 0 0 1 1 1 0 xx71
0 1 0 0 1 1 1 0 xx72
1 1 0 0 1 1 1 0 xx73
0 0 1 0 1 1 1 0 xx74
1 0 1 0 1 1 1 0 xx75
0 1 1 0 1 1 1 0 xx76
1 1 1 0 1 1 1 0 xx77
0 0 0 1 1 1 1 0 xx78
1 0 0 1 1 1 1 0 xx79
0 1 0 1 1 1 1 0 xx7A
1 1 0 1 1 1 1 0 xx7B
0 0 1 1 1 1 1 0 xx7C
1 0 1 1 1 1 1 0 xx7D
0 1 1 1 1 1 1 0 xx7E
1 1 1 1 1 1 1 0 xx7F
OCH570C
