1. Switches to the [Parameter] screen.
2. Switches to the [Batch monitor] screen.
3. Switches to the [Operation Command] screen.
4. Switches between the screens. The blue switch that indicates the currently displayed screen does not
switch the screen.
5. Indicates unused switches for base screen switching.
6. Switches to the previously opened screen.
7. Displays the current date and time. Touch the date and time to open the [Clock Setting] window.
8. Opens the [Language Setting] window.
・ When a system alarm occurs, the alarm message will appear at the lower portion of the screen. Touching
the left end of the message changes the display position of the message in the order of upper, center, and
lower. Touching the other part of the message displays the [Alarm Reset] window.
