5.4 Device List
Some of the devices specified to the on-screen switches and lamps, etc., are also used for common settings of
functions such as scripts. Using [Batch Edit] is recommended to change these devices in a batch. For the details on
[Batch Edit], please refer to “11.8.3 Changing the set values in a batch (Batch Edit)” in " GT Designer3 (GOT2000)
Screen Design Manual ".
5.4.1 Label: No.100 Com_Label
Label name
Data type
Assigned
(Device)
Application
u16_Com_CngBsDv
Unsigned BIN16
GD65200
Screen switch device (base screen)
u16_Com_CngOvrRpDv1
Unsigned BIN16
GD65201
Screen switch device
(overlap window 1)
u16_Com_CngOvrRpDv2
Unsigned BIN16
GD65204
Screen switch device
(overlap window 2)
u16_Com_CngOvrRpDv3
Unsigned BIN16
GD65207
Screen switch device
(overlap window 3)
u16_Com_CngOvrRpDv4
Unsigned BIN16
GD65210
Screen switch device
(overlap window 4)
u16_Com_CngOvrRpDv5
Unsigned BIN16
GD65213
Screen switch device
(overlap window 5)
u16_Com_CngSprInpsDv1
Unsigned BIN16
GD65216
Screen switch device
(superimpose window 1)
u16_Com_CngSprInpsDv2
Unsigned BIN16
GD65217
Screen switch device
(superimpose window 2)
u16_Com_CngDlgDv
Unsigned BIN16
GD65218
Screen switch device (dialog window)
s16_Com_CngLngDv
Signed BIN16
GD65221
Language switch device
s16_Com_CngSytmLanDv
Signed BIN16
GD65222
System language switch device
s16_Com_StmInfRd
Signed BIN16 [0..2]
GD65231
System information: reading device
s16_Com_StmInfWt
Signed BIN16[0..38]
GD65241
System information: writing device
u16_Com_DocIDNum
Unsigned BIN16
GD65280
Document display: ID
u16_Com_DocPageNum
Unsigned BIN16
GD65281
Document display: page No.
u16_Com_DocStNtcDspDv
Unsigned BIN16
GD65282
Document display:
state display notice device
u16_Com_DocEndPageNum
Unsigned BIN16
GD65283
Document display:
final page No. notice device
u16_Com_RcpCmCntlDv
Unsigned
BIN16 [0..2]
GD65290
Recipe common settings:
external control information
u16_Com_RcpCmNtcDv
Unsigned
BIN16 [0..2]
GD65293
Recipe common settings:
external notice information
u16_Com_StChgDv
Unsigned BIN16
GD65296
Statinon number switching device
