Mitsubishi FR-A800 Series - 3.2 Controller Settings of Screen Design Software; 3.3 Ethernet Controller Settings of Screen Design Software

7/83
BCN-P5999-1045-1a
3.2 Controller Settings of Screen Design Software
Item
Set value
Remarks
GOT NET No.
1
GOT Station No.
18
GOT Communication Port No.
5036
Retry (Times)
3
Startup Time (Sec)
3
Timeout Time (Sec)
3
Delay Time (ms)
0
GOT Ethernet Setting
Item
Set value
Remarks
Update GOT Ethernet Standard Port Setting
Checked
GOT IP Address
192.168.3.18
Subnet Mask
255.255.255.0
Default Gateway
0.0.0.0
Peripheral S/W Communication Port No.
5015
Transparent Port No.
5014
3.3 Ethernet Controller Settings of Screen Design Software
Host
Net No.
Station
Unit Type
IP Address
Port No.
Communication
1
*
1
1
FREQROL
192.168.3.50
5001
UDP
3.4 Overlap Window Settings of Screen Design Software
To close the window screen when switching base screens, the [Close the window when switching base
screens] box is checked in [Detail Setting] of Overlap Window in [Screen Switching/Window Setting].
The [Disable the touch operation of a screen on the back] box is checked for overlap window 3.
3.5 Graphics Mode (Graphics Setting)
The graphics mode of this sample screens is GOT Graphic Ver.2.
The screen design used in this sample is [Basic-Gray].
In GOT Graphic Ver.2, the background of overlap windows become semitransparent.
4. Inverter FR-A800-E
4.1 Inverter FR-A800-E Communication Settings
Item
Parameter
Set value
Operation mode selection
Pr.79
0
Communication startup mode selection
Pr.340
10
NET mode command source selection
Pr.550
5
PU mode command source selection
Pr.551
2
Ethernet communication network number
Pr.1424
1
Ethernet communication station number
Pr.1425
1
Ethernet function selection 1
Pr.1427
5001
Ethernet IP address 1
Pr.1434
192
Ethernet IP address 2
Pr.1435
168
Ethernet IP address 3
Pr.1436
3
Ethernet IP address 4
Pr.1437
50
Set the parameters above from the operation panel (FR-DU08) or FR Configurator2.
After the settings, the inverter will start with NET operation mode when the power is on (reset). To change
parameters via GOT, switch the inverter to the NET operation mode.
Pressing the key on the inverter body switches between the NET and PU operation modes.
