1. OUTLINE
This manual explains the sample screens of GOT2000 connected to a FR-A800-E (FR-A820-0.4K-E1)
inverter via Ethernet. The sample screens can be used to change the running speed, rotation direction, and the
parameters as well as to monitor the current values and execute machine diagnosis (load characteristics
measurement).
This sample screen can also be used for connecting GOT2000 and MELSEC iQ-R/Q/L series PLC via
Ethernet and then connecting the PLC and the inverter via Ethernet interface unit*1/CC-Link IE Field Network
master/local module*2. *3
For the procedures of changing the screen data, please refer to “7. Others”.
*1: Used for the FR-A800(FR-A820-0.4K-E1) inverter
*2: Used for the FR-A800(FR-A820-0.4K-GF) inverter
*3: Connection via CC-Link IE Field Network limits the operation command and the operation of the machine
diagnosis (load characteristics measurement). For details, please refer to “7.2.8 precautions”.
2. SYSTEM CONFIGURATION
*1: The SD card is used for the recipe function and document display function.
*2: The battery is used to backup the clock data and the recipe data in the SRAM user area in case of power
failures. (The battery is included as standard in the GOT.)
*3: For more details on the cable, please refer to “15.3.1 Connection to FREQROL-A800/F800” in "GOT2000
Series Connection Manual (Mitsubishi Products)".
* This sample screen can also be used for connecting to inverters via PLC. For details, please refer to
“7. Others”.
* This sample assumes the inverter connection via the channel No.1, network No.1 and station No.1 to 16.
When the inverter is connected via other channels, networks or station numbers, the settings have to be
customized. For details, please refer to “7. Others”.
3. GOT
3.1 System Applications that are Automatically Selected
Type
System Application Name
Standard Function
Standard System Application
Standard Font
Japanese
Communication Driver
Ethernet Connection
Ethernet(FREQROL(Batch monitor)), Gateway
Extended Function
Standard Font
Chinese (Simplified)
Outline Font
Gothic
Alphanumeric/Kana
Japanese(Kanji)
Chinese(Simplified)
Key Window Design Information
KANA KANJI Conversion
Recipe Display (Record List)
Document Display
Ethernet cable*3
GOT2000
・ GT27**－V(640×480)
・ Interface:
Standard I/F(Ethernet)
・ SD card *1
・ Battery (GT11-50BAT) *2
・FR-A820-0.4K-E1
・Interface:
Ethernet
Motor
Hub
・FR-A820-0.4K-E1
・Interface：
Ethernet
Motor
Up to 16 devices can be connected.
