Mitsubishi FR-A800 Series User Manual

9/83
BCN-P5999-1045-1a
5.2.2 Screen list/transition (individual)
Base screen B-12000: Menu
Base screen B-12010: Startup
Base screen B-12100:
Parameter1
Base screen B-12020: Operation
Base screen B-12200 to 12202:
Batch monitor
Base screen B-12010:
Refer to “Startup”
Base screen B-12030:
Maintenance
Base screen B-12010: Startup
Base screen B-13100:
Operation Command
Window screen W-12010:
Station Number Switching
Switching
Window screen W-12100:
Parameter Recipe Settings
Window screen W-12101:
Backup Confirmation Dialog
Window screen W-12102:
Restoration Confirmation Dialog
Base screen B-12020
shown in the next page:
Refer to “Operation”
Base screen B-12090:
Manual Display
Window screen W-12010:
Station Number Switching
Base screen B-12030
shown in the next page:
Refer to “Maintenance”
