Mitsubishi FX2N User Manual

FX2N-32DP-IF Profibus-DP Interface Unit Introduction 1
1-5
1.3.1 Connected Programming Tools
An FX-20P-E or personal computer can be used to monitor the devices of the 32DP-IF or to
set parameter data for special function blocks connected to the 32DP-IF. For operating instruc-
tions of the FX-20P-E or personal computer, refer to their respective operation manuals. For
device numbers and explanation, refer to chapter 4.
Connecting cable is same as FX
0N
/FX
2N
programmable controller.
Table 1.2:
Connected Programming Tools
Monitoring Tools Description
FX-20P-E
“Device Monitor”, “Data Change” and “Forced ON/OFF” in the Online
Monitor /Test mode can be used for supported devices.
Personal Computer
(MELSEC MEDOC PLUS)
“Device Edit” and “Entry Data Monitor” can be used for supported
devices.

Mitsubishi FX2N Specifications

General

Type	PLC
Series	FX2N
Manufacturer	Mitsubishi Electric
Power Supply	100-240VAC or 24VDC
Program Capacity	8, 000 steps
I/O Points	Up to 256 points
Expansion	Yes, via expansion modules
Instruction Set	Basic and advanced instructions
Output Type	Relay or Transistor
Humidity	5 to 95% RH, non-condensing
Communication	RS-422, RS-485
Input Points	Up to 128 points
Output Points	Up to 128 points
Execution Speed	0.08 µs per instruction
Programming Language	Instruction List
Data Memory	8, 000 words
Operating Temperature	0 to 55°C
Storage Temperature	-20°C to 70°C
