4. Advanced Devices
4.1 Data Registers
*1 If the 32DP-IF is in data exchange mode, the sent data to a DP-master can be monitored
by reading data registers D0 ~ D99 in the programming tool.
For example of allocating device, refer to section 4.1.1.
*2 If the 32DP-IF is in data exchange mode, the received data from a DP-master can be
monitored by reading data registers D100 ~ D199 in the programming tool.
For example of allocating device, refer to section 4.1.1.
*3 The data registers D200 to D299 contain the user parameter data which sent by the DP-
master. After power on, when the 32DP-IF is in the search baud rate state or the wait
parameter state, these data register contain the default parameter data.
For user parameter, refer to chapter 6. For default parameter settings, refer to appendix
A.
Table 4.1:Supported Data Register List
Items Description
D0 ~ D99
Input (sent) data to DP-master
*1
D100 ~ D199
Output (received) data from DP-master
*2
D200 ~ D299
Parameter data
*3
FX2N-32DP-IF Profibus-DP Interface Unit
