Mitsubishi FX2N User Manual

FX2N-32DP-IF Profibus-DP Interface Unit Advanced Devices 4
4-10
4.2.4 Error Status (M8060 ~ M8069 and D8060 ~ D8069)
Table 4.11:Special Auxiliary Relays (M8060 ~ M8069)
Diagnostic
Device
Name Check Points
M8060
(

) (

)
(ref. D8060,
D8061)
I/O configuration error
If this flag is ON, check error code in D8060,
D8061 and extension cable.
M8061
(

) (

)
(ref. D8060,
D8061)
32DP-IF hardware error If this bit is ON, check error code in D8061.
M8062, M8063 Reserved
M8064
(

) (

)
(ref. D8064
Parameter error
If this flag is ON, check error code inD8064 and
DP-master setting.
M8065, M8066 Reserved
M8067
(

) (

)
(ref. D8067)
Operation error
If this flag is ON, check error code in D8067 and
D8068, DP-master parameter, and the extension
cable.
M8068
(

)
(ref. D8068)
Parameter error and operation
error
If M8064 or M8067 is ON, this bit would be set to
ON. This bit is cleared by resetting the power
supply.
M8069 Reserved
