FX2N-32DP-IF Profibus-DP Interface Unit Specifications 3
3-2
3.3 Performance Specifications
Table 3.3:Performance Specifications
Items Specifications
Maximum Number of Controllable
I/O Points
Maximum 256 points (see section 1.3)
Transmission data
(Maximum exchanged data length)
400bytes can be sent and received during one bus cycle.
(input: 200 bytes, output: 200 bytes)
Transmission Type Bus network
Connector
9 pin D-SUB Connector for Profibus-DP network
8 pin mini DIN
Connector for FX-20P-E or personal computer (MELSEC
MEDOC PLUS)
Supported Baud
Rates and Bus
Length (bps)
9.6k, 19.2k,
45.45k, 93.75k
1,200 m (3,937')
187.5k 1,000 m (3,281')
500k 400 m (1,312')
1.5M 200 m (656')
3M, 6M, 12M 100 m (328')
LED Indicators
POWER LED ON when AC power is supplied.
RUN LED
ON when 32DP-IF is exchanging data with extension I/O blocks/
units and special function blocks.
BF LED ON when a communication error is detected. (No data exchange)
DIA LED ON when notice of diagnostic data is detected.

Mitsubishi FX2N Specifications

General

Type	PLC
Series	FX2N
Manufacturer	Mitsubishi Electric
Power Supply	100-240VAC or 24VDC
Program Capacity	8, 000 steps
I/O Points	Up to 256 points
Expansion	Yes, via expansion modules
Instruction Set	Basic and advanced instructions
Output Type	Relay or Transistor
Humidity	5 to 95% RH, non-condensing
Communication	RS-422, RS-485
Input Points	Up to 128 points
Output Points	Up to 128 points
Execution Speed	0.08 µs per instruction
Programming Language	Instruction List
Data Memory	8, 000 words
Operating Temperature	0 to 55°C
Storage Temperature	-20°C to 70°C
