Appendix A:
Default Parameter <After Power ON>
A-1 User Parameter <After Power ON>
Figure A-1:User Parameter <After Power ON>
*1 Type code of special function block is as following table. This code in the parameter must
be written first Lower byte and second higher byte
*2 After power on, the default setting of this parameter for every special function block is 2.
User Parameter for 32DP-IF
Byte No. 0
1
Bit 0 Bit 1 Bit 2
Meaning
Reserved
(must be 0)
Swap data flag
I/O block status is
checked in every
cycle: Y/N
Special function
block’s BFM #29
(Error status) is
checked: Y/N.
Description
Default setting is
OFF (0), byte data
are not swapped
within a word.
Default setting is
OFF (0), the status
check of the I/O
units/blocks is not
performed in every
cycle.
Default setting is
OFF (0), BFM #29
of all connected
special function
blocks is not
checked in every
cycle.
User Parameter for First Special Function Block
Byte No.
3
4 5 6
Meaning
Type code of special
function block, lower
byte of BFM 30
*1
Type code of special
function block,
higher byte of BFM
30
*1
Total length m of
parameter data for
this special function
block.
Contains n = 0, as
BFM addresses will
be assigned dynam-
ically
*3
Description
m = 2
*2
.....
User Parameter for Last (y
*4
th) Special Function Block
Byte No.
.....
2 + 4
×
(y
*4
- 1) + 1
....
2 + 4
×
y
*4
Meaning
.....
Type code of special
function block, lower
byte of BFM 30
*1
.....
Contains n = 0, as
BFM addresses will
be assigned dynam-
ically
*3
Description
Table A-1: Type Code of Special Function Blocks
Type BFM 30 Code Dec BFM30 Code Hex
FX
2N
-4AD K2010 07DA Hex
FX
2N
-4AD-TC K2030 07EE Hex
FX
2N
-4AD-PT K2040 07F8 Hex
FX
2N
-4DA K3020 0BCC Hex
FX2N-32DP-IF Profibus Interface unit
