FX2N-32DP-IF Profibus-DP Interface Unit Advanced Devices 4
4-9
4.2.3 Configuration Status (M8040 ~ M8059 and D8040 ~ D8059)
M8040 ~ M8059 are reserved. The configuration bytes in D8040 ~ D8059 define the amount of
data which is exchanged between the corresponding I/O units/blocks, special function blocks
and the DP-master.
*1 This value shows as following Figure.
Ex.1 10 hex = 1 byte (8 bit) inputs not consistent
Ex.2 63 hex = 4 word outputs not consistent
Figure 4.4:Configuration Data
Table 4.10:Special Data Registers (D8040 ~ D8059)
Diagnostic Device Name Description
D8040 (

)
Lower 8 bits
Configuration data 1
*1
The data registers D8040~D8055 display the
actual configuration of the node station. After
power on, when the 32DP-IF is in the search
baud rate state or in the wait configuration
state, these data registers contain the default
configuration data.
Higher 8bits
Configuration data 2
*1
D8041 (

)
Lower 8 bits
Configuration data 3
*1
Higher 8bits
Configuration data 4
*1
D8042 (

)
Lower 8 bits
Configuration data 5
*1
Higher 8bits
Configuration data 6
*1
:
:
:
:
D8055 (

)
Lower 8 bits
Configuration data 31
*1
Higher 8bits
Configuration data 32
*1
D8056 ~ D8059 Reserved
Length of data
00 = 1 byte/word
:
:
15 = 16 byte/word
Input/output
00 = Special format
01 = Input
10 = Output
11 = Input and output
Byte/Word
0 = Byte
1 = Word
Consistency
0 = Consistency of byte/word
1 = Consistency of entir length
bit 0
bit 7
