FX2N-32DP-IF Profibus-DP Interface Unit Advanced Devices 4
4-8
Note 4: Error status
Data register D8029 reflects the error status of the 32DP-IF. In case of a general error (bit 0
= ON) the module tries to send a static diagnosis to the DP-master. In this case normal data
exchange is not possible. If bit 0 returns to the Off state, the static diagnosis message is
also reset.
The definition of the error bit is shown in the table below.
Table 4.9:Error status in D8029
Bit No. Description 0 (OFF) 1 (ON)
Bit 0 general error No general error
This bit is ON if one or more error bits (bit 2, 6,
7) are ON. Check Bit 2, 6 and 7 in D8029.
Bit 1 Reserved
Bit 2
External 24 V power
error
Power supply is
normal
DC 24 V power supply failure
Bit 3 ~ 5 Reserved
Bit 6
(ref. Table
4.11)
I/O bus error No I/O bus error
I/O bus error occurred. Check extension bus
cable for I/O extension units/blocks and error
code in D8060.
Bit 7
(ref. Table
4.11)
Operation error No operation error
Operation error occurred. Check extension bus
cable for special function blocks, and DP-mas-
ter parameter, and error code in D8067 and
D8068.
Bit 8, 9 Reserved
Bit 10
(ref. Table
4.11)
configuration error
Configuration
data valid
Invalid configuration data received. Check con-
figuration for 32DP-IF in the DP-master and
D8040 ~ D8055.
Bit 11
(ref. Table
4.11)
Parameter error
Parameter data
valid
Invalid parameter data received. Check param-
eter for 32DP-IF in the DP-master and D200 ~
D299, and error code in D8064and D8068.
Bit 12 ~ 14 Reserved
Bit 15 RUN/STOP status
RUN/STOP
switch is in RUN
position
RUN/STOP switch is in STOP position
