Specifications 3
3-1
3. Specifications
3.1 General Specifications
3.2 Power Supply Specifications
Table 3.1:General Specifications
Item Description
Operating Temperature 0 to 55 °C (32 to 131 °F)
Storage Temperature -20 to 70 °C (-4 to 158 °F)
Operating Humidity 35 to 85% Relative Humidity, No condensation
Storage Humidity 35 to 90% Relative Humidity, No condensation
Vibration Resistance
- Direct Mounting
Conforms to JIS C0040; 10 - 57 Hz: 0.75 mm Half Amplitude
57 - 150 Hz: 9.8 m/s
2
Acceleration
Sweep Count for X, Y, Z: 10 times (80 min in each direction)
Vibration Resistance
- DIN rail Mounting
Conforms to JIS C0040; 10 - 57 Hz: 0.035 mm Half Amplitude
57 - 150 Hz: 4.9 m/s
2
Acceleration
Sweep Count for X, Y, Z: 10 times (80 min in each direction)
Shock Resistance
Conforms to JIS C0041: 147m/s
2
Acceleration, Action Time: 11 ms
3 times in each direction X, Y, and Z
Noise Immunity 1,000 Vp-p, 1microsecond, 30 - 100 Hz, tested by noise simulator
Dielectric Withstand Voltage 1,500 V AC > 1 min, tested between all points, terminals and ground
Insulation Resistance 5 M
Ω
> at 500 V DC, tested between all points, terminals and ground
Grounding Class 3 (Grounding resistance is 100
Ω
or less)
Planned Certifications CE
Table 3.2:Power Supply Specifications
Item Description
Power Supply 100 ~ 240 V AC +10% -15%, 50/60 Hz
Max. Allowable Momentary
Power Failure Period
10 ms at 100 V AC
(< 10 ms, 32DP-IF = RUN continue, > 10 ms, 32DP-IF = power down)
Fuse (size) Rating 3 A <
φ
5
×
20 mm (0.2
×
0.79 inches)>
In-rush Current 100 V AC Max. 40 A < 5 ms, 200 V AC Max. 60 A < 5 ms
Power Consumption 35 VA
24 V DC Service Supply 500 mA
Max. 5 V DC Bus Supply 220 mA
FX2N-32DP-IF Profibus-DP Interface Unit
To Next Page
