Mitsubishi FX2N User Manual

User Parameter 6
6-1
6. User Parameter
6.1 User Parameter Rules
Some bytes of input data and output data exchanged with the DP-master (the 32DP-IF’s con-
figuration) must be defined by user parameter. Also defined by user parameters are how the
exchanged data should be distributed between the available I/O points and special function
blocks. Some applications require initial settings, like gain and offset of analog blocks. For
these purposes, the 32DP-IF requires a set of parameter data, which must be determined by
the user parameter.
For “after power on” parameter, refer appendix A. For user parameter example, refer to appen-
dix B.
Note:
User parameters become valid for 32DP-IF and special function blocks (ex. FX
2N
-4AD, FX
2N
-
4DA).
*1 m
1
, m
2
: Total length of parameter data for this special function block.
Table 6.1:User Parameter Configuration
Byte No.
User parameter
for 32DP-IF
0
1
User parameter
for first special
function block
2
:
:
1 + (2 + m
1
*1
)
User parameter
for second special
function block
1 + (2 + m
1
*1
) +1
:
:
1 + (2 + m
1
*1
) + (2 +m
2
*1
)
:
:
:
:
