FX2N-32DP-IF Profibus-DP Interface Unit Advanced Devices 4
4-11
Table 4.12:Special Data Registers (D8060 ~ D8069)
Diagnostic
Device
Name
Error
code
Description
D8060 (
)
(
)
I/O configuration
error
This device contains the lowest device address that caused the
error. Check D8061
D8061 (
)
(
)
32DP-IF hard-
ware error
0 No error
6102
Operation circuit error: Please contact a service represen-
tative.
6103
I/O bus error: Check extension cable for Extension I/O
units/blocks.
6129
BFM #29 (error status) of a connected special function
block shows a value that is different from “0”. Please
check the diagnosis message at the DP-master.
D8062, D8063 Reserved
D8064 (
)
(
)
Parameter error
0 No error
6406
Parameter error for extension units/blocks: Check error
code in D8068, and parameter in the DP-master.
6407
Parameter length error: Parameter data too long, check
parameter’s length in the DP-master.
D8065,D8066 Reserved
D8067 (
)
(
)
Operation error
0 No error
6708
Operation error: Operation error for transmitting special
function block is occurred, check error code in D8068, and
DP-master parameter, and extension cable.
D8068 (
)
(
)
Parameter error
and operation
error
This device contains the lowest special function block’s address
that caused the error. Check D8064 and D8067.
D8069 Reserved
